Designs

“In an 8-bit world, every byte matters, and every transistor tells a story.”

ESP/Arduino Date and Time

There's no need for a clock chip

The Arduino cores for the ESP8266 and ESP32 natively support the current date and time, synchronised to NTP servers. There is no need for a real-time clock chip or for extra libraries.

Timing Matters

Read/Write Timing - Poor design and a wasted gate

I sometimes see 8-bit CPU interfacing to memory using an output enable signal (OE) to the memory device that is generated by combining (NANDing) the read/write (R/W) line with the CPU enable (E), as shown above, in a similar way to the write enable signal (WE). This is poor design and should be avoided.
